Plastic Glass S.r.l. designs and manufactures GRP / FRP Scrubbers of any height and diameter, up to 4,8 metres with Filament Winding technology, according to customer's drawings and requirements.
Available type of fiberglass Scrubbers:
Plastic Glass S.r.l. has been present on the market for gases and liquid depuration systems from more than 30 years, constantly developing new solutions to improve plant efficiency, reduce construction costs and simplify Scrubbers maintenance operations.
All internal accessories for the gases treatment such as Demisters, Retention Grids, Liquid Distribution Systems and Spray Banks can be supplied directly from Plastic Glass S.r.l. guaranteeing customer ready-to-use appliances according to specific requirements.
Each component installed on the GRP / FRP Scrubber and Washing Columns of Plastic Glass S.r.l. is manufacture directly into the interior workshop or is provided by selected and historical suppliers able to adapt their standards to project directives.
Plastic Glass S.r.l. is historically recognized as a highly specialized company in the production of Thermoplastic Liners (PVC, PP, PVDF, HALAR, ...) and External Coatings for protection from aggressive chemical and atmospheric environments.
In addition, specific Refractory and Insulation support systems have been developed to meet the needs
of all customers.
Thanks to the dedicated technical office, Plastic Glass S.r.l. can support its customers with immediate feedback about:
Plastic Glass S.r.l. can also provide GRP Platform and Ladders suitable for all types of loads, supporting the customers even during plant installation phases.
MARINE SOx SCRUBBER
Scrubbers in GRP for Nautics
Installed on Ships for the break down of sulfur
oxides in the exhausted gases.
Dimensions and layout completely customizable to accommodate the specific space availability.
- Internal diameter every 100 mm: DN500, DN600, ...
DN1000, DN1100, ... DN1900, DN2000, ... .
- No limitation in total height
- Tailor made nozzles layout
- Temperature up to 130°C
SCRUBBER IN PVC + GRP
Treatment of Sulfur Dioxide
Scrubber supplied ready for use complete with demister,
gases deflector and double spray bar.
- Internal Diameter: 1.800 mm
- Total Height: 10.500 mm
- Design Temp.: + 50 °C
- Design Press.: - 0,05 barg
- Site: Italy
Washing Column in PP+GRP
Complete with internal vortex gas distributor.
Design according to EN13121-3 : 2016.
- Internal Diameter: 3.800 mm
- Total Height: 23.500 mm
- Design Temp.: + 60 °C
- Design Press.: - 65 mbar
- Site: Ravenna (Italy)
Treatment of Sulfur Dioxide
Design for seismic acceleration up to 1 g.
Internal support plate for N° 9 filtering elements.
- Internal Diameter: 3.000 mm
- Total Height: 13.100 mm
- Design Temp.: + 75 °C
- Design Press.: + 0,1 barg
- Site: Japan
N° 2 Two-Stage Scrubbers
Scrubbers of 240 m3 capacity in integral monolitic structures completely realized
with Filament Winding Technology.
- Internal Diameter: 4.500 mm
- Total Height: 17.900 mm
- Design Temp.: +80 °C
- Design Press.: -0,15 / +0,5 barg
- Site: Saudi Arabia
